Annotations

In addition to the basic OCR functionality, Mistral Document AI API adds the annotations functionality, which allows you to extract information in a structured json-format that you provide. Specifically, it offers two types of annotations:

  • bbox_annotation: gives you the annotation of the bboxes extracted by the OCR model (charts/ figures etc) based on user requirement and provided bbox/image annotation format. The user may ask to describe/caption the figure for instance.
  • document_annotation: returns the annotation of the entire document based on the provided document annotation format.
annotations_explanation_graph

Key capabilities:

  • Labeling and annotating data
  • Extraction and structuring of specific information from documents into a predefined JSON format
  • Automation of data extraction to reduce manual entry and errors
  • Efficient handling of large document volumes for enterprise-level applications

Common use cases:

  • Parsing of forms, classification of documents, and processing of images, including text, charts, and signatures
  • Conversion of charts to tables, extraction of fine print from figures, or definition of custom image types
  • Capture of receipt data, including merchant names and transaction amounts, for expense management.
  • Extraction of key information like vendor details and amounts from invoices for automated accounting.
  • Extraction of key clauses and terms from contracts for easier review and management

How it works​

annotations_workflow_graph

BBOX Annotations

  • All document types:
    • After regular OCR is finished; we call a Vision capable LLM for all bboxes individually with the provided annotation format.

Document Annotation

  • pdf/image:
    • Independent of OCR; we convert all pages into images and send all images to a Vision capable LLM along with the provided annotation format.
  • pptx/docx/...:
    • We run OCR first and send the output text markdown to a Vision capable LLM along with the provided annotation format.

You can use our API with the following document formats:

In these examples, we will only consider the OCR with pdf format.

BBox Annotation​

Here is an example of how to use our Annotation functionalities using the Mistral AI client and Pydantic:

Define the Data Model

First, define the response formats for BBox Annotation using Pydantic models:

from pydantic import BaseModel

# BBOX Annotation response formats
class Image(BaseModel):
  image_type: str
  short_description: str
  summary: str

You can also provide a description for each entry, the description will be used as detailed information and instructions during the annotation; for example:

from pydantic import BaseModel, Field

# BBOX Annotation response formats
class Image(BaseModel):
  image_type: str = Field(..., description="The type of the image.")
  short_description: str = Field(..., description="A description in english describing the image.")
  summary: str = Field(..., description="Summarize the image.")

Start the completion

Next, use the Mistral AI python client to make a request and ensure the response adheres to the defined structures using bbox_annotation_format set to the corresponding pydantic models:

import os
from mistralai import Mistral, DocumentURLChunk, ImageURLChunk, ResponseFormat
from mistralai.extra import response_format_from_pydantic_model

api_key = os.environ["MISTRAL_API_KEY"]

client = Mistral(api_key=api_key)

# Client call
response = client.ocr.process(
    model="mistral-ocr-latest",
    document=DocumentURLChunk(
      document_url="https://arxiv.org/pdf/2410.07073"
    ),
    bbox_annotation_format=response_format_from_pydantic_model(Image),
    include_image_base64=True
  )
Example output

BBOX Image

bbox-image

Image Base 64

{
}

BBOX Annotation Output

{
  "image_type": "scatter plot",
  "short_description": "Comparison of different models based on performance and cost.",
  "summary": "The image consists of two scatter plots comparing various models on two different performance metrics against their cost or number of parameters. The left plot shows performance on the MM-MT-Bench, while the right plot shows performance on the LMSys-Vision ELO. Each point represents a different model, with the x-axis indicating the cost or number of parameters in billions (B) and the y-axis indicating the performance score. The shaded region in both plots highlights the best performance/cost ratio, with Pixtral 12B positioned within this region in both plots, suggesting it offers a strong balance of performance and cost efficiency. Other models like Qwen-2-VL 72B and Qwen-2-VL 7B also show high performance but at varying costs."
}

Document Annotation​

Here is an example of how to use our Document Annotation functionality using the Mistral AI client and Pydantic:

Define the Data Model

First, define the response format for Document Annotation using a Pydantic model:

from pydantic import BaseModel

# Document Annotation response format
class Document(BaseModel):
  language: str
  chapter_titles: list[str]
  urls: list[str]

Start the completion

Next, use the Mistral AI python client to make a request and ensure the response adheres to the defined structures using document_annotation_format set to the corresponding pydantic model:

import os
from mistralai import Mistral, DocumentURLChunk, ImageURLChunk, ResponseFormat
from mistralai.extra import response_format_from_pydantic_model

api_key = os.environ["MISTRAL_API_KEY"]

client = Mistral(api_key=api_key)

# Client call
response = client.ocr.process(
    model="mistral-ocr-latest",
    pages=list(range(8)),
    document=DocumentURLChunk(
      document_url="https://arxiv.org/pdf/2410.07073"
    ),
    document_annotation_format=response_format_from_pydantic_model(Document),
    include_image_base64=True
  )
Example output

Document Annotation Output

{
  "language": "English",
  "chapter_titles": [
    "Abstract",
    "1 Introduction",
    "2 Architectural details",
    "2.1 Multimodal Decoder",
    "2.2 Vision Encoder",
    "2.3 Complete architecture",
    "3 MM-MT-Bench: A benchmark for multi-modal instruction following",
    "4 Results",
    "4.1 Main Results",
    "4.2 Prompt selection",
    "4.3 Sensitivity to evaluation metrics",
    "4.4 Vision Encoder Ablations"
  ],
  "urls": [
    "https://mistral.ai/news/pixtal-12b/",
    "https://github.com/mistralai/mistral-inference/",
    "https://github.com/mistralai/mistral-evals/",
    "https://huggingface.co/datasets/mistralai/MM-MT-Bench"
  ]
}

BBoxes Annotation and Document Annotation​

Here is an example of how to use our Annotation functionalities using the Mistral AI client and Pydantic:

Define the Data Model

First, define the response formats for both BBox Annotation and Document Annotation using Pydantic models:

from pydantic import BaseModel

# BBOX Annotation response format
class Image(BaseModel):
  image_type: str
  short_description: str
  summary: str

# Document Annotation response format
class Document(BaseModel):
  language: str
  chapter_titles: list[str]
  urls: list[str]

You can also provide a description for each entry, the description will be used as detailed information and instructions during the annotation; for example:

from pydantic import BaseModel, Field

# BBOX Annotation response format with description
class Image(BaseModel):
  image_type: str = Field(..., description="The type of the image.")
  short_description: str = Field(..., description="A description in english describing the image.")
  summary: str = Field(..., description="Summarize the image.")

# Document Annotation response format
class Document(BaseModel):
  language: str
  chapter_titles: list[str]
  urls: list[str]

Start the completion

Next, use the Mistral AI python client to make a request and ensure the response adheres to the defined structures using bbox_annotation_format and document_annotation_format set to the corresponding pydantic models:

import os
from mistralai import Mistral, DocumentURLChunk, ImageURLChunk, ResponseFormat
from mistralai.extra import response_format_from_pydantic_model

api_key = os.environ["MISTRAL_API_KEY"]

client = Mistral(api_key=api_key)

# Client call
response = client.ocr.process(
    model="mistral-ocr-latest",
    pages=list(range(8)),
    document=DocumentURLChunk(
      document_url="https://arxiv.org/pdf/2410.07073"
    ),
    bbox_annotation_format=response_format_from_pydantic_model(Image),
    document_annotation_format=response_format_from_pydantic_model(Document),
    include_image_base64=True
  )
Example output

BBOX Image

bbox-image

Image Base 64

{
}

BBOX Annotation Output

{
  "image_type": "scatter plot",
  "short_description": "Comparison of different models based on performance and cost.",
  "summary": "The image consists of two scatter plots comparing various models on two different performance metrics against their cost or number of parameters. The left plot shows performance on the MM-MT-Bench, while the right plot shows performance on the LMSys-Vision ELO. Each point represents a different model, with the x-axis indicating the cost or number of parameters in billions (B) and the y-axis indicating the performance score. The shaded region in both plots highlights the best performance/cost ratio, with Pixtral 12B positioned within this region in both plots, suggesting it offers a strong balance of performance and cost efficiency. Other models like Qwen-2-VL 72B and Qwen-2-VL 7B also show high performance but at varying costs."
}

Document Annotation Output

{
  "language": "English",
  "chapter_titles": [
    "Abstract",
    "1 Introduction",
    "2 Architectural details",
    "2.1 Multimodal Decoder",
    "2.2 Vision Encoder",
    "2.3 Complete architecture",
    "3 MM-MT-Bench: A benchmark for multi-modal instruction following",
    "4 Results",
    "4.1 Main Results",
    "4.2 Prompt selection",
    "4.3 Sensitivity to evaluation metrics",
    "4.4 Vision Encoder Ablations"
  ],
  "urls": [
    "https://mistral.ai/news/pixtal-12b/",
    "https://github.com/mistralai/mistral-inference/",
    "https://github.com/mistralai/mistral-evals/",
    "https://huggingface.co/datasets/mistralai/MM-MT-Bench"
  ]
}

Cookbooks​

For more information and guides on how to make use of OCR, we have the following cookbooks:

FAQ​

Q: Are there any limits regarding the Document Intelligence API?
A: Yes, there are certain limitations for the Document Intelligence API. Uploaded document files must not exceed 50 MB in size and should be no longer than 1,000 pages.

Q: Are there any limits regarding the Annotations?
A: When using Document Annotations, the file cannot have more than 8 pages. BBox Annotations does not have the same limit.
